    75kw Top Feed Vibroflotation Device For Vibro Sand Compaction Project

    Ask Lasest Price
    Brand Name : BVEM
    Model Number : BJV75E-377
    Certification : ISO 9001
    Price : negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 300 sets per year
    Delivery Time : 10 workdays
    • Product Details
    • Company Profile

    75kw Top Feed Vibroflotation Device For Vibro Sand Compaction Project


    75kw top feed vibrofloation device used for vibro sand compaction project


    75kW Vibroflot Spec.
    TypeBJV75E-377
    Power/kW75
    Rotation speed/rpm1450
    Amplitude (at Tip)/mm17.5
    Centrifugal force/kN188
    Weight /kg1828
    Diameter/mm377
    Length/mm2783
    Diameter of the work pile/mm(700-1200)

    The working principle of vibroflot


    The working principle of the vibrator is that the special motor mobilizes the eccentric block within the vibrating body through coupling, generating centrifugal force, and causing horizontal vibration of the whole vibrator. The vibrator can be applied in the construction of packing vibro pile and compaction vibro pile. It is applicable for the consolidation of foundations such as gravelly soil, sandy soil, silt soil, cohesive soil, artificial soil and collapsible soil etc., as well as increasing density and resisting liquefaction of various types of liquefiable soil. After vibration shock process, the stratum can stand a certain degree of dynamic load, and can improve bearing capacity of foundation soil, relative density and liquefaction resistance capacity.
