    426mm 75kW Vibroflotation Method Construction Device For Stone Column Making

    Ask Lasest Price
    Brand Name : BVEM
    Model Number : BJV75E-426
    Certification : ISO 9001:2015
    Price : negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 600 sets per year
    Delivery Time : 15 work days
    • Product Details
    • Company Profile

    426mm 75kW Vibroflotation Method Construction Device For Stone Column Making


    426mm 75kW vibroflot equipment construction device for stone column making


    Vibroflot Spec.
    TypeBJV75E-426
    Power/kW75
    Rotation speed/rpm1450
    Amplitude (at Tip)/mm16
    Centrifugal force/kN180
    Weight /kg2018
    Diameter/mm426
    Length/mm2783
    Diameter of the work pile/mm(800-1200)

    Beijing vibroflotation engineer machinery co.,ltd(BVEM)

    BVEM is the largest manufacturer of electrical vibroflot in Asia and one of the authors of Chinese vibroflot manufacturing code.

    As the active pusher of VIBRIFLOTATION and the professional supplier of vibroflot, BVEM has developed VIBRIFLOTATION application and supplied vibroflot equipment to 33 countries all over the world.With the enterprise mission of "OUTPERFORM to SERVE VIBRIFLOTATION", BVEM product was widespread in more and more countries with excellent reputation which came from the high recognition of high performance product and the top level whole process service.


    Vibro compaction
    Under the effect of vibration, the saturated sand soil liquefaction happen,which make the sand particles re-arranged and the soil interspace reduced.
    Boring
    By vibration and the flushing of water and/or air, the vibroflot penetrates to the designed depth.
    Compaction
    Compact the soil section by section up to the gound according to the requirements of the compaction current, compaction time and sectional compaction length.


    VIBROFLOTATION is one of a typical technique which is a widely used application for foundation soil improvement. In VIBROFLOTATION construction, vibroflot equipment makes a joint action of horizontal vibration and high pressure water shock to compact the loose sand layer or formed in soft soil of gravel column to compose the composite foundation with original soil together, finally achieve the improvement of soil by load capacity, settlement controlling as well as the anti-seismic capacity.
