    180kN 75kw Electrical Vibroflotation Device

    Ask Lasest Price
    Brand Name : BVEM
    Model Number : BJV75E-426
    Certification : ISO 9001:2015
    Price : negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 300 sets per year
    Delivery Time : 10 workdays
    • Product Details
    • Company Profile

    180kN 75kw Electrical Vibroflotation Device


    Electrical vibroflotation device to improve soft foundation driving stone column pile 75kW


    75kW Vibroflot Spec.
    TypeBJV75E-426
    Power/kW75
    Rotation speed/rpm1450
    Amplitude (at Tip)/mm16
    Centrifugal force/kN180
    Weight /kg2018
    Diameter/mm426
    Length/mm2783
    Diameter of the work pile/mm(800-1200)

    Vibroflot characteristics

    • Gravel or backfill sand is filled from top of borehole
    • The most commonly used vibroflotation equipment
    • Used for vibro compaction and vibro replacement construction in general condition
    • Economy and efficient vibro construction method

    The working principle of vibroflot


    The working principle of the vibrator is that the special motor mobilizes the eccentric block within the vibrating body through coupling, generating centrifugal force, and causing horizontal vibration of the whole vibrator. The vibrator can be applied in the construction of packing vibro pile and compaction vibro pile. It is applicable for the consolidation of foundations such as gravelly soil, sandy soil, silt soil, cohesive soil, artificial soil and collapsible soil etc., as well as increasing density and resisting liquefaction of various types of liquefiable soil. After vibration shock process, the stratum can stand a certain degree of dynamic load, and can improve bearing capacity of foundation soil, relative density and liquefaction resistance capacity.


    180kN 75kw Electrical Vibroflotation Device180kN 75kw Electrical Vibroflotation Device
