    100kW vibroflotation device for vibro compaction improving foundation liquefaction resistance

    Ask Lasest Price
    Brand Name : BVEM
    Model Number : BJV100E-377
    Certification : ISO 9001:2015
    Price : Negotiable
    Payment Terms : L/C, T/T, MoneyGram
    Supply Ability : 600 sets per year
    Delivery Time : 15 work days
    • Product Details
    • Company Profile

    100kW vibroflotation device for vibro compaction improving foundation liquefaction resistance


    100kW vibroflotation device for vibro compaction improving foundation liquefaction resistance


    Vibroflot Spec.
    TypeBJV100E-377BJV100E-426
    Power/kW100100
    Rotation speed/rpm1450-18001450
    Amplitude (at Tip)/mm1917.2
    Centrifugal force/kN180208
    Weight /kg18802073
    Diameter/mm377426
    Length/mm32152883
    Diameter of the work pile/mm(700-1200)(800-1200)



    Vibroflotation techniques


    Vibro compaction
    Under the effect of vibration, the saturated sand soil liquefaction happen,which make the sand particles re-arranged and the soil interspace reduced.


    Boring
    By vibration and the flushing of water and/or air, the vibroflot penetrates to the designed depth.
    Compaction
    Compact the soil section by section up to the gound according to the requirements of the compaction current, compaction time and sectional compaction length.


    Vibro replacement
    Jet water and vibrate by vibroflot to form holes. Fill in pile holes by section with solid filling materials such as gravel (cobble) etc., to finally form composited foundation.


    Boring
    By vibration and the flushing of water and/or air, the vibroflot penetrates to the designed depth.
    Backfill
    Fill stones into the bore-hole, and compact section by section up to the ground according to the requirements of compaction current and the sectional compaction length.


    BVEM· The top-level researcher of Vibrator in China


    As the leader of vibroflotation industry in China, BVEM focus on vibroflotation market and formed a business platform with vibroflotation technique as core, on which there are three main business including the manufacturing and integration of VIBRIFLOTATION equipment, sales and service for vibroflotation equipment and foundation improvement construction undertaking.


    BVEM is the largest manufacturer of electrical vibroflot in Asia and one of the authors of Chinese vibroflot manufacturing code.
    As the active pusher of vibroflotation and the professional supplier of vibroflot, BVEM has developed vibroflotation application and supplied vibroflot equipment to 33 countries all over the world.With the enterprise mission of "OUTPERFORM to SERVE VIBRIFLOTATION", BVEM product was widespread in more and more countries with excellent reputation which came from the high recognition of high performance product and the top level whole process service.
