    Eco - Friendly Bottom Feed Vibroflot Electric Vibroflotation 1800rpm

    Ask Lasest Price
    Brand Name : BVEM
    Model Number : BJZC-BFS-400-180
    Certification : ISO 9001:2015
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 300 sets per year
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Eco - Friendly Bottom Feed Vibroflot Electric Vibroflotation 1800rpm

    High efficiency vibroflot equipment with bottom feed system and powerful motor BJZC-V400-180

    The Bottom Feed Electrical Vibroflot Spec.
    TypeBJZC-BFS-400-180
    Power(kW)180
    Rotation speed(rpm)1200-1800
    Working pile diameter (mm)900-1200
    System pressure(bar)6
    Vibration force(kN)200-300
    Hopper volume(m³)1.2
    Pipe diameter(mm)DN250
    Control typeInverter Control
    Cooling-down methodCirculating water cooling
    Air flow rate(m³/min)10
    Vibrator size L/W/H(mm)2600×600×700

    Profile of Bottom Feed Vibroflotation:

    Bottom feed method vbroflotation construction need a special vibroflot equipment with bottom feed system to realize. This professional equipment are commonly composed of :

    1. Electrical or hydraulic vibroflot system ( vibroflot, damper, extension tube and electrical cabinet )

    2. Feeding system ( feeding tube , damper )

    3. Stock bin system ( double bin or single bin )

    4. Material supply system ( lifting hopper )

    5. Controlling system ( Valve controlling , air pressure controlling, material level controlling )

    Due to the diversity of engineering condition, bottom feed vibroflot need to be customized for production.


    BVEM profile (Beijing vibroflotation engineer machinery co.,ltd)


    1.The first one who introduced and studied vibro compact method in China
    2. The first one who developed application in Chinese projects
    3. Has the top experts of vibroflotation tech. and experienced construction management team
    4. China first one who reserched and produced vibrators
    5. China first and only one who produced the Bottom Feed Vibroflot
    6.The first one who produced domestic hydraulic-driven vibrator
    7. All types&models coverage:30kw-260kw
    8. Editor-in-cheif of industry standards <Technical Specification of Vibroflotation Method in Hydrauelectric and Water Resources Projects>(DL/T5214-2005)
    9. Editor-in chelf of industry standrds <Electrical Deep Vibrator>(DL/T 1557-2016)
    10. China first one who developed vibroflotation application in variety of industry(thermal power,hydraulic power, petrochemical, highway,rail, port etc.)
    11. Cooperate with DI and support to formulate the design and construction scheme
