    Vibro Densification Bottom Feed Vibroflot 180kW With Dry Method System

    Ask Lasest Price
    Brand Name : BVEM
    Model Number : BJZC-BFS-400-180
    Certification : ISO 9001:2015
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 300 sets per year
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    Vibro Densification Bottom Feed Vibroflot 180kW With Dry Method System

    BJZC-V400-180 bottom feed vibroflot with dry method system used for vibro compaction construction

    The Bottom Feed Electrical Vibroflot Spec.
    TypeBJZC-BFS-400-180
    Power(kW)180
    Rotation speed(rpm)1200-1800
    Working pile diameter (mm)900-1200
    System pressure(bar)6
    Vibration force(kN)200-300
    Hopper volume(m³)1.2
    Pipe diameter(mm)DN250
    Control typeInverter Control
    Cooling-down methodCirculating water cooling
    Air flow rate(m³/min)10
    Vibrator size L/W/H(mm)2600×600×700
    The bin size L/W/H(mm)4800×1300×(1300-1500)
    Extension tube size L/W/H(mm)12000×300×600


    Profile of Bottom Feed Vibroflotation:

    Bottom feed method vbroflotation construction need a special vibroflot equipment with bottom feed system to realize. This professional equipment are commonly composed of :

    1. Electrical or hydraulic vibroflot system ( vibroflot, damper, extension tube and electrical cabinet )

    2. Feeding system ( feeding tube , damper )

    3. Stock bin system ( double bin or single bin )

    4. Material supply system ( lifting hopper )

    5. Controlling system ( Valve controlling , air pressure controlling, material level controlling )

    Due to the diversity of engineering condition, bottom feed vibroflot need to be customized for production.


    BVEM profile (Beijing vibroflotation engineer machinery co.,ltd)

    China first use of 75KW vibrator for the 30-meter depth sand soil treatment(three gorges project)
    China first use of hydraulic vibrator for the treatment of the 240-meter chimney foundation
    China first use of hydulic vibrator for the treatment of 32m depth foundation of hydraulic power station
    The first one in China who treated the base of oil storage tank with a diameter of more than 60m by vibroflotation method
