    High Performance Bottom Feed Vibroflot Underwater Offshore Stone Column Construction

    Ask Lasest Price
    Brand Name : BVEM
    Model Number : BJZC-BFS-400-180
    Certification : ISO 9001:2015
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 300 sets per year
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    High Performance Bottom Feed Vibroflot Underwater Offshore Stone Column Construction

    High performance vibroflot equipment used for bottom feed vibroflotation construction BJZC-V400-180

    The Bottom Feed Electrical Vibroflot Spec.
    TypeBJZC-BFS-400-180
    Power(kW)180
    Voltage(V)380
    Frequency(Hz)50
    Rotation speed(rpm)1200-1800
    Working pile diameter (mm)900-1200
    System pressure(bar)6
    Vibration force(kN)200-300
    Hopper volume(m³)1.2


    Profile of Bottom Feed Vibroflotation:

    As a extension of vibroflotation technique, bottom feed method created a larger range of vibroflotation application. In terms of its feature, vibroflotation can be conducted to treat the foundation in those projects even under following situation:

    1. Silty or silty clay soil with undrained shearing strength less than 20Kpa

    2. Underwater or offshore stone column construction

    3. Projects under the strict controlling of pile diameter

    4. Place where the water resource are used in limitation

    5. Place where the waste water are strictly prohibit to discharge


    Bottom feed method vbroflotation construction need a special vibroflot equipment with bottom feed system to realize. This professional equipment are commonly composed of :

    1. Electrical or hydraulic vibroflot system ( vibroflot, damper, extension tube and electrical cabinet )

    2. Feeding system ( feeding tube , damper )

    3. Stock bin system ( double bin or single bin )

    4. Material supply system ( lifting hopper )

    5. Controlling system ( Valve controlling , air pressure controlling, material level controlling )

    Due to the diversity of engineering condition, bottom feed vibroflot need to be customized for production.


    BVEM profile (Beijing vibroflotation engineer machinery co.,ltd)

    China first use of 75KW vibrator for the 30-meter depth sand soil treatment(three gorges project)
    China first use of hydraulic vibrator for the treatment of the 240-meter chimney foundation
    China first use of hydulic vibrator for the treatment of 32m depth foundation of hydraulic power station
    The first one in China who treated the base of oil storage tank with a diameter of more than 60m by vibroflotation method
