    Top Feed Vibroflot Equipment Compaction Soil Improvement Project

    Ask Lasest Price
    Brand Name : BVEM
    Model Number : BJV180E-426
    Certification : ISO 9001:2015
    Price : Negotiable
    Payment Terms : L/C, T/T, MoneyGram
    Supply Ability : 600 sets per year
    Delivery Time : 15 work days
    • Product Details
    • Company Profile

    Top Feed Vibroflot Equipment Compaction Soil Improvement Project


    BVEM Top Feed Vibroflot Application Cases in Vibroflotation Compaction Soil Improvement Project


    Top Feed Vibroflot Spec.
    TypeBJV75E-426BJV130E-426BJV180E-426BJV260E-450
    Power/kW

    75

    130180260
    Centrifugal force/kN180208276520
    Weight /kg2018232025863280
    Diameter/mm426426426450
    Length/mm2783296331003400
    Diameter of the work pile/mm(800-1200)(800-1200)(800-1200)(1000-1500)


    Top Feed Vibroflot Application Case


    Vibroflotation compaction treatment of c3206 bid section of Hong Kong No. 3 aircraft runway project



    The project adopts double hang of top feed vibroflot of 180kW for compaction construction, the pile spacing is up to 4.2m, and the compaction effect meets the design requirements of 95% relative compactness.


    Malaysia Guantan wharf artificial reclamation project


    180kW top feed vibro float equipment is used in the project for vibroflotation compaction of 600000 square meters of marine backfill sand.


    Compaction vibroflotation in Marsa Al arab phase 2 Dubai,Reem Island Development project Abu Dhabi and the Island Jumeirah Dubai



    260kw top feed vibroflot device is applied to vibroflotation compaction construction in sand foundation, the vibroflotation range of pile body can reach 4 ~ 5m.


    Vibroflotation benefits


    The deep vibro techniques present a very versatile ground improvement method that can be adjusted to a wide variety of ground conditions and foundation requirements. Its execution is comparatively fast even if large volumnes of soil are to be improved and subsequent structural works can follow very quickly.The soil improvement enables the contractor to utilise standard shallow footings which,in turn,leads to additional savings.
    Another advantage is the environmental friendliness of vibro techniques,as natural and in situ materials are used. In addition, only a comparatively small quantity of soil is removed during the process.


    China Vibroflot Supplier - BVEM· The top-level researcher of Vibrator in China


    Researched and produced vibrators in power of 30KW,55KW,75KW since 1977 to 2005
    Researched and produced 150kw vibrator in 2006
    Researched and produced 180kw vibrator in 2009
    Produced Bottom Feed Vibrator with double lock pressure bunker in 2012
    Researched and produced 260kw vibrator in 2014
    Researched and produced Z125 Hydraulic-driven vibrator in 2014
    Lauched Vibrator performance testing equipment in 2014
